| Operating parameter | Performance | Remark |
| Operating frequency | 850.125~930.125 | Support ISM band |
| Tx power | 22 dBm | - |
| Receiving sensitivity | -147dbm | Air data rate is 2.4kbps |
| Air data rate | 0.3k~62.5kbps | Controlled via user's programming |
| Distance for reference | 7000m | Test condition：clear and open area, antenna gain: 5dBi，antenna height: 2.5m，air data rate: 2.4kbps |
| Operating parameter | Performance | Remark |
| Size | 16 * 26 mm | - |
| Antenna | IPEX/stamp hole | 50 ohm impedance |
| Communication interface | UART | - |
| Package | SMD | - |
| Main parameter | Min. | Typ. | Max. | Unit | Remark |
| Operating voltage | 2.3 | 5.0 | 5.5 | V | ≥5.0 V ensures output power |
| Communication level | - | 3.3 | - | V | For 5V TTL, It is recommended to add level conversion |
| TX current | - | 155 | - | mA | Instant power consumption |
| RX current | - | 11 | - | mA | - |
| Sleep current | - | 2 | - | μA | Software is shut down |
| Operating temperature | -40 | - | +85 | ℃ | - |
| No. | Name | Direction | Function |
| 1 | GND | - | Ground |
| 2 | GND | - | Ground |
| 3 | GND | - | Ground |
| 4 | GND | - | Ground |
| 5 | M0 | Input（weak pull-up） | Work with M1 to decide 4 working modes of module (not suspended, if not used, could be grounded). |
| 6 | M1 | Input（weak pull-up） | Work with M0 to decide 4 working modes of module (not suspended, if not used, could be grounded). |
| 7 | RXD | Input | TTL UART inputs, connects to external (MCU, PC) TXD output pin. Can be configured as open-drain or pull-up input. |
| 8 | TXD | Output | TTL UART outputs, connects to external RXD (MCU, PC) input pin. Can be configured as open-drain or push-pull output. |
| 9 | AUX | Output | To indicate module ’ s working status & wakes up the external MCU.During the procedure of self-check initialization, the pin outputs low level.Can be configured as push-pull output (suspending is allowed). |
| 10 | VCC | - | Power supply ：2.3~ 5.2V DC |
| 11 | GND | - | Ground |
| 12 | NRST | Input | - |
| 13 | GND | - | Ground |
| 14 | NC | - | - |
| 15 | NC | - | - |
| 16 | NC | - | - |
| 17 | NC | - | - |
| 18 | NC | - | - |
| 19 | GND | - | Ground |
| 20 | GND | - | Ground |
| 21 | ANT | - | Antenna |
| 22 | GND | - | Ground |
