[IC]:-
[Frequency]:855~931.5MHz
[Power]:13dBm
[Distance]:1.5km
[Interface]:UART
[Introduction]:E43-900T13S3 is an ultra-high performance-to-price wireless data transmission module launched by Ebyte. It has four working modes and two transmission modes. Each transmission mode has its own characteristics and can be applied to various application scenarios.
| RF Parameter | Value | Remark |
| Working frequency | 855~931.5 MHz | Support ISM band |
| Transmitting power | 13 dBm | - |
| Receiving sensitivity | -126 dBm | Air data rate is 2.4kbps |
| Air data rate | 1.2k~9.6kbps | User Programming Control |
| Test distance | 1500m | Test condition：clear and open area, antenna gain: 5dBi，air data rate:1.2kbps |
| Hardware Parameter | Value | Remark |
Size | 16 * 26 mm | - |
Antenna type | IPEX / Stamp hole | 50 ohm impedance |
Communication interface | UART | - |
Package | SMD | - |
| Electronic parameter | Min. | Typ. | Max. | Unit | Condition |
| Power supply | 2.3 | 5 | 5.5 | V | ≥3.3 V ensures output power |
| Communication level | - | 3.3 | - | V | For 5V TTL, it may be at risk of burning down |
| Transmitting current | - | 33.1 | - | mA | Instant power consumption |
| Receiving current | - | 12.7 | - | mA | - |
| Sleep current | - | 2.0 | - | nA | Software is shut down |
| Operating temperature | -40 | - | +85 | ℃ | Industrial design |
| Operating humidity | 10 | - | 90 | % | - |
| Storage temperature | -40 | - | +125 | ℃ | - |
| Pin No. | Pin Item | Pin Direction | Pin Application |
| 1 | GND | - | Ground |
| 2 | GND | - | Ground |
| 3 | GND | - | Ground |
| 4 | GND | - | Ground |
| 5 | M0 | Input (weak pull-up) | Work with M1 & decide the four operating modes; Floating is not allowed, can be ground. |
| 6 | M1 | Input (weak pull-up) | Work with M0 & decide the four operating modes; Floating is not allowed, can be ground. |
| 7 | RXD | Input | TTL UART inputs, connects to external TXD output pin; Can be configured as open-drain or pull-up input. |
| 8 | TXD | Output | TTL UART outputs, connects to external RXD input pin Can be configured as open-drain or push-pull output. |
| 9 | AUX | Output | To wake up the external MCU, during the procedure of self-check initialization, the pin outputs low level; Can be configured as open-drain output or push-pull output; Floating is allowed. |
| 10 | VCC | - | Voltage positive reference of module; Power supply 2.3V ~ 5.2V DC |
| 11 | GND | - | Ground |
| 12 | NC | - | - |
| 13 | GND | - | Ground |
| 14 | NC | - | - |
| 15 | NC | - | - |
| 16 | NC | - | - |
| 17 | NC | - | - |
| 18 | NC | - | - |
| 19 | GND | - | Ground |
| 20 | GND | - | Ground |
| 21 | ANT | - | Antenna |
| 22 | GND | - | Ground |
