[IC]:TLSR8269
[Frequency]:2.400~2.483GHz
[Protocol]:BLE 4.2
[Distance]:50m
[Interface]:UART
[Weight]:0.9±0.1g
[introduction]:E104-BT10 is a Bluetooth mesh network module designed and manufactured by Ebyte Electronic Technology Co., Ltd., which conforms to the sig mesh V1.0 standard. The single network can accommodate up to 10922 node devices.
| RF Parameter | Value | Remark |
| Working frequency | 2400~2483.5 MHz | ISM band |
| Transmitting power | 8 dBm | - |
| Receiving sensitivity | -92 dBm | Air data rate is 1Mbps |
| Test distance | 50m | Testcondition：clear and open area, antenna height: 2.5m，air data rate: 1Mbps |
| Hardware Parameter | Value | Remark |
Size | 19 * 13 mm | - |
Antenna type | PCB | 50Ω impedance |
Communication interface | UART | 4800～230400bps |
Package | SMD | - |
| Electronic parameter | Min. | Typ. | Max. | Unit | Condition |
| Voltage supply | 1.9 | 3.3 | 3.6 | V | ≥3.3 V ensures output power |
| Communication level | - | 3.3 | - | V | For 5V TTL, it may be atrisk of burning down |
| Transmitting current | - | 29 | - | mA | Instant power consumption |
| Receiving current | - | 29 | - | mA | - |
| Operating temperature | -40 | - | +85 | ℃ | - |
| Operating humidity | 10 | - | 90 | % | - |
| Storage temperature | -40 | - | +125 | ℃ | - |
| No. | Pin item | Pin direction | Application |
| 1 | GND | - | Ground,connecting to power source reference ground |
| 2 | PE0 | PWM output | Correspondsto green indicator of SIGMESH HSL |
| 3 | PE1 | PWM output | Correspondsto red indicator of SIGMESH HSL |
| 4 | DM | - | GPIO |
| 5 | DP | - | GPIO |
| 6 | PA0 | - | GPIO |
| 7 | PA1 | - | GPIO |
| 8 | PA3 | - | GPIO |
| 9 | PA4 | - | GPIO |
| 10 | PA7 | - | GPIO |
| 11 | SWS | - | Program download interface |
| 12 | PB1 | - | GPIO |
| 13 | PB4 | Output | Networking indicator, when succeed pin outputs high level |
| 14 | PB5 | - | GPIO |
| 15 | PB6 | PWM output | Correspondsto blue indicator of SIGMESH HSL |
| 16 | PB7 | - | GPIO |
| 17 | TXD | Output | UART TX pin for transmitting |
| 18 | RXD | Input | UART RX pin for receiving |
| 19 | VCC | - | Power supply, 1.9V ~ 3.6V (recommend to add external ceramic filter capacitor) |
| 20 | GND | - | Ground,connecting to power source reference ground |
| 21 | PC5 | - | GPIO |
| 22 | PC4 | - | GPIO |
| 23 | PD2 | - | GPIO |
| 24 | PD3 | - | GPIO |
| 25 | RST | Input | Chip reset initiation input pin, valid under low level |
| 26 | GND | - | Ground,connecting to power source reference ground |
