[IC]:CC2540
[Frequency]:2.402~2.480GHz
[Protocol]:BLE 4.0
[Distance]:60m
[Interface]:USB
[introduction]:E104-2G4U04A is a small Bluetooth wireless module designed and manufactured by Chengdu Ebyte, USB type (pin spacing 1.27mm). This module has a high-performance PCB on-board antenna, using low power consumption Bluetooth (BLE) SOC solution.
| RF Parameter | Value | Remark |
| Working frequency | 2.402~2.480 GHz | Support ISM band |
| Transmitting power | 4 dBm | - |
| Receiving sensitivity | -94 dBm | Air data rate is 250kbps |
| Test distance | 60m | Test condition：clear and open area,antenna height: 2.5m, air data rate: 250kbps |
| Hardware Parameter | Value | Remark |
| IC | CC2540F256RHAR/QFN40 | - |
| FLASH | 256 KB | - |
| SRAM | 8 KB | - |
| Core | 8051 mcu | - |
| Size | 59 * 18 mm | With case |
| Power supply | USB | - |
| Protocol | BLE 4.0 | - |
| Electronic parameter | Min | Type | Max | Unit | Remark |
| Operating voltage | 2.7 | 5 | 5.5 | V | USB power supply |
| Operating voltage | 2.0 | 3.3 | 3.6 | V | On-board power supply |
| Communication level | - | 3.3 | - | V | For 5V TTL, it may be atrisk of burning down |
| TX current | - | 31.5 | - | mA | - |
| RX current | - | 22 | - | mA | - |
| Sleep current | - | - | - | μA | - |
| Operating temperature | -40 | - | 85 | ℃ | Industrial class |
| Storage temperature | -40 | 20 | +125 | ℃ | - |
| Pin No. | Item | Direction | Description |
| 1 | P1.4 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 2 | P1.5 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 3 | P1.6 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 4 | P1.7 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 5 | VCC | Power supply | 2.0V-3.6V (please avoid power supply with USB) |
| 6 | DD | Input/Output | Program download port P2_1(see CC2540 chip datasheet for details) |
| 7 | DC | Input/Output | Program download port P2_2(see CC2540 chip datasheet for details) |
| 8 | RESET | Input | Reset (there is a reset circuit inside the product) |
| 9 | GND | Power supply | Ground |
| 10 | P0.2 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 11 | P0.3 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 12 | P0.4 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 13 | P0.5 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 14 | P0.6 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 15 | P0.7 | Input/Output | General purpose IO port(see CC2540 datasheet for details) |
| 16 | LED | Signal indication | Connect to P1.1 of CC2540,high level will drive to light up |
| 17 | LED | Signal indication | Connect to P0.0 of CC2540, lowlevel will drive to light up |
| 18 | Button | Button | Connect to P1.3 of CC2540, low level active |
| 19 | Button | Button | Connect to P1.2 of CC2540, low level active |
