E28-2G4M12S

[IC]:SX1280

[Frequency]:2.4~2.5GHz

[Power]:12.5dBm

[Distance]:3.0km

[Interface]:SPI

[Weight]:1.6±0.1g

[Introduction]:E28-2G4M12S is a 2.4GHz bluetooth module designed by Chengdu Ebyte. With built-in PCB antenna, it adopts the original RFIC SX1280 of Semtech, it works at 2.400 ~ 2.500GHz with ultra-low power consumption. It is applicable for smart home, security system & etc.

en-E28-2G4M12S_01
1000

en-E28-2G4M12S_02

en-E28-2G4M12S_04

en-E28-2G4M12S_05


RF ParameterValue
Remark
Working frequency
2400~2500 MHz

Default: 2.4GHz (52MHz oscillator)

Transmitting power12.5 dBm

About 18mW

Receiving sensitivity-130 dBm

Air data rate: 125kbps

Air data rate0.125M~2Mbps

Default: 125kbps

Test distance3000m

In open and clear air, with maximum power, 5dBi antenna gain, height of 2m,

air data rate: 125kbps


Hardware ParameterValue
Remark
Size
24*15mm
Antenna typeIPEX / PCB
Communication interfaceSPI


PackageSMD




Electronic parameterMin.Typ.Max.UnitCondition
Power supply
1.83.33.6V
Communication level1.83.33.6V
Transmitting current

42

4550mA12.5dBm(18mW)
Receiving current9
1011mA

Sleep current123μA
Operating temperature
-4020
+85
Operating humidity
1060
90%
Storage temperature
-4020
+125


E28(2G4M12S)_Size

Pin No
Pin itemPin directionPin application
1VCC-

Power supply, 1.8V ~3.6V (recommend to add external ceramic filter capacitor)

2GND-

Ground, connecting to power source reference ground

3MISO_TXOutput

SPI data output pin,can be used as UART transmitting pin

4MOSI_RXInput

SPI data input pin,can be used as UART receiving pin

5SCK_RTSNInput

SPI clock input pin,can be used as UART request transmitting pin

6NSS_CTSInput

Module chip selection pin, used to start a SPI communication; and can be used as UART

clearing transmitting pin

7GND-

Ground, connecting to power source reference ground

8GND-

Ground, connecting to power source reference ground

9NRESETInput

Chip reset initiation input pin, valid under low level, built-in 50k pull-up resistor

10BUSYOutput

Status indication (referto SX1280 Datasheet)

11DIO1Input/Output

Configurable general IO interface (refer to SX1280 Datasheet)

12DIO2Input/Output

Configurable general IO interface (refer to SX1280 Datasheet)

13DIO3Input/Output

Configurable general IO interface (refer to SX1280 Datasheet)

14GND-

Ground, connecting to power source reference ground
