[Frequency]:225~237.6MHz
[Power]:37dBm
[Distance]:15km
[Interface]:RS232/RS485
[Weight]:238±5g
[Introduction]:E90-DTU is a wireless data transceiver with the function of digital data processing,digital modulation and demodulation,FEC,balanced soft decision,etc.It provides transparent RS232/RS485 interface,different with the analog FM transceiver plus MODEM analog digital transceiver.
| RF Parameter | Value | Remark |
| Working frequency | 225~237.6 MHz | Default: 230MHz |
| Transmitting power | 37 dBm | About 5W |
| Air data rate | 1.2k~70kbps | Default: 1.2kbps |
| Test distance | 15000 meter | In open and clear air, with maximum power, 5dBi antenna gain, height of 2m. |
| Hardware Parameter | Value | Remark |
| Size | 102 * 105 * 25 mm | Without interface |
| Antenna type | SMA-K | |
| Communication interface | RS232 / RS485 | Standard DB9 Hole/3.81 connecting terminal |
| Baud rate | 9600 | Baud rate: 1200~115200 |
| Buffer | 512 bytes buffer | Automatically sub-packaging with 186 bytes per package |
| Electronic parameter | Min. | Typ. | Max. | Unit | Condition |
| Power supply | 10 | 12 | 28 | V | |
| Transmitting current | 933 | 1037 | 1140 | mA | 37dBm（5W） |
| Stand-by current | 37 | 41 | 45 | mA | |
| Operating temperature | -40 | 20 | +85 | ℃ | |
| Operating humidity | 10 | 60 | 90 | % | |
| Storage temperature | -40 | 20 | +125 | ℃ |
| Pin No. | Name | Function | Description |
| 1 | DB-9 femal socket | RS-232 interface | Standard RS-232 interface |
| 2 | 3.81 connecting terminal | RS-485, power interface | Standard RS-485 and screwing interface |
| 3 | PWR-LED | Power indicator | Red when powered-on |
| 4 | TXD-LED | Transmitting indicator | Yellow, it flashes when transmitting data |
| 5 | RXD-LED | Receiving indicator | Yellow, it flashes when receiving data |
| 6 | DC power interface | Power interface | Straight hole, outer diameter: 5.5mm, inner diameter: 2.5mm |
| 7 | DIP switch | DIP switch | Working mode control |
| 8 | Antenna interface | SMA-K | External thread hole.L: 10mm. 50Ω resistance. |
