| 产品 型号 | Interface | IC | Frequency Hz | Power dBm | Distance km | Air data rate | Package | Size (mm) | Feature | 技术 手册 | 样品 购买 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| E32-900MBL-01 | USB | - | - | - | - | - | - | 53*27mm | E32 series module test board | ||
| E32-400MBL-01 | USB | - | - | - | - | - | - | 53*27mm | E32 series module test board | ||
| E32-400M20S | SPI | SX1278 | 433M 470M | 20 | 5 | - | SMD | 14 * 20 | Long transmission distance,Strong penetration diffraction | ||
| E32-433T20S | UART | SX1278 | 433M | 20 | 5.0 | 2.4k～19.2k | SMD | 16 * 26 | LoRa Spread Spactrum Technology | ||
| E32-400M30S | SPI | SX1278 | 433M 470M | 30 | 10 | 0.018K~37.5K | SMD | 24 * 38.5 | Long transmission distance,Strong penetration diffraction | ||
| E32-900M20S | SPI | SX1276 | 868M 915M | 20 | 5 | 0.018K~37.5K | SMD | 14*20 | Long transmission distance,Strong penetration diffraction | ||
| E32-900T30D | UART | SX1276 | 868M 915M | 30 | 8 | 0.3k~19.2k | DIP | 24*43 | LoRa spread spectrum | ||
| E32-900T20S | UART | SX1276 | 868M 915M | 20 | 5.5 | 0.3k~19.2k | SMD | 16*26 | LoRa spread spectrum | ||
| E32-900M30S | UART | SX1276 | 868M 915M | 30 | 10 | 0.018k~37.5k | SMD | 24*38.5 | Long transmission distance,Strong penetration diffraction | ||
| E32-433T20DT | UART | SX1278 | 433M | 20 | 3.0 | 0.3k~19.2k | DIP | 21*36 | LoRa spread spectrum | ||
| E32-915T20S | UART | SX1276 | 915M | 20 | 3 | 0.3k~19.2k | SMD | 16 * 26 | LoRa spread spectrum | ||
| E32-868T20S | UART | SX1276 | 868M | 20 | 3 | 0.3k~19.2k | SMD | 16 * 26 | LoRa spread spectrum | ||
| E32-DTU(433L27) | 232/485 | SX1278 | 433M | 27 | 5.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(433L37) | 232/485 | SX1278 | 433M | 37 | 20 | 0.3k~9.6k | Screwing/DB9 | 124*105*25 | LoRa spread spectrum | ||
| E32-400T20S3 | UART | SX1278 | 433M 470M | 20 | 3 | 0.3k~19.2k | SMD | 16 * 26 | LoRa spread spectrum | ||
| E32-915T30S | UART | SX1276 | 915M | 30 | 8.0 | 0.3k~19.2k | DIP | 25*40.3 | LoRa spread spectrum Continuous transmiss | ||
| E32-868T30S | UART | SX1276 | 868M | 30 | 8.0 | 0.3k~19.2k | DIP | 25*40.3 | LoRa spread spectrum Continuous transmiss | ||
| E32-433T30S | UART | SX1278 | 433M | 30 | 8.0 | 0.3k~19.2k | SMD | 25*40.5 | LoRa spread spectrum | ||
| E32-433T20S1 | UART | SX1278 | 433M | 20 | 3.0 | 0.3k~19.2k | SMD | 17*25.5 | LoRa spread spectrum | ||
| E32-433T20S2T | UART | SX1278 | 433M | 20 | 3.0 | 0.3k~19.2k | SMD | 17*30 | LoRa spread spectrum | ||
| E32-DTU(170L30) | 232/485 | SX1278 | 170MHz | 30 | 8.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(868L30) | 232/485 | SX1276 | 868M | 30 | 8.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(868L20) | 232/485 | SX1276 | 868M | 20 | 3.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(915L30) | 232/485 | SX1276 | 915M | 30 | 8.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(915L20) | 232/485 | SX1276 | 915M | 20 | 3.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(433L20) | 232/485 | SX1278 | 433M | 20 | 3.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-DTU(433L30) | 232/485 | SX1278 | 433M | 30 | 8.0 | 0.3k~9.6k | Screwing/DB9 | 82*62*25 | LoRa spread spectrum | ||
| E32-915T30D | UART | SX1276 | 915M | 30 | 8.0 | 0.3k~19.2k | DIP | 24*43 | LoRa spread spectrum | ||
| E32-868T30D | UART | SX1276 | 868M | 30 | 8.0 | 0.3k~19.2k | DIP | 24*43 | LoRa spread spectrum | ||
| E32-170T30D | UART | SX1278 | 170M | 30 | 8.0 | 0.3k~19.2k | DIP | 24*43 | LoRa Spread Spectrum | ||
| E32-433T30D | UART | SX1278 | 433M | 30 | 8.0 | 0.3k~19.2k | DIP | 24*43 | LoRa spread spectrum | ||
| E32-868T20D | UART | SX1276 | 868M | 20 | 3.0 | 0.3k~19.2k | DIP | 21*36 | LoRa spread spectrum | ||
| E32-915T20D | UART | SX1276 | 915M | 20 | 3.0 | 0.3k~19.2k | DIP | 21*36 | LoRa spread spectrum | ||
| E32-433T20DC | UART | SX1278 | 433M | 20 | 3.0 | 0.3k~19.2k | DIP | 21*36 | LoRa spread spectrum | ||
| E32-433T27D | UART | SX1278 | 433M | 27 | 5.0 | 0.3k~19.2k | DIP | 24*43 | LoRa spread spectrum |
