NB114 UART to Ethernet Serial Server

[Interface]:UART(RS485、RS422、RS232)、ethernet(RJ45)

[Size]:82*84*25mm

[Weigth]:126g ± 5g

[Introduction]:NB114 is a serial server that realizes serial data ⇌ Ethernet data conversion.The product comes with RJ45 interface and guide rail installation.With multiple Modbus gateway modes, it can meet the networking functions of various serial devices/PLCs.

01
02
03
04
05
06
07
08
09
10
11

No.
ItemRemark
1Operating voltage
DC 8~28V
2Interface
UART(RS485、RS422、RS232)、Ethernet(RJ45)
3Working mode

TCP Server、TCP Client、UDP Server、UDP Clientdefault TCP Server)

4Socket links

Support 6 ways

5Network protocol

IP、TCP/UDP、IPv4

6IP acquisition method
DHCP、static IP(default static IP)
7DNS
Support
8configuration
Web、configuring tools、AT commands
9IP address
Customizable(default 192.168.3.7)
10Local port
Customizable(default 8887)
11Subnet mask
255.255.255.0
12Gateway
Customizable(default 192.168.3.1)
13Target IP
Customizable(default 192.168.3.3)
14Target port
Customizable(default 8888)
15Network cache
512 Byte
16Serial cache
512 Byte
17Packaging mechanism
512 Byte
18Serial port baud rate
1200 ~ 230400 bps(default 115200)
19Data bit
5、6、7、8(default 8)
20Stop bit
1、2(default 1)
21Check Digit
None、 Odd、Even、Mark、Space(default None)
22Stream Control

RTS/CTS、DSR/DTR、XON/XOFF、NONE(default NONE)

23Size
82 mm * 84 mm * 25 mm (length*width*height)
24Weight
126g ± 5g
25Working temperature and humidity
-40 ~ +85℃、5% ~ 95%RH(No condensation)
26Storage temperature and humidity
-40 ~ +105℃、5% ~ 95%RH(No condensation)

NB114引脚
